Les ex vw d'érik.... toutes restaurées par ses soins.
___________________________________________________________________
été 2004
Erik à trouvé un nouveau joujou de 61 qui était resté stocké depuis des années, rapatrillé vite fait à la maison et remise en qqs semaines!!
___________________________________________________________________
Juin 2004
la 67 reçoit le 2.4L
2003 au Nat's
Pour les run N° 89, tps : 9.675s avec le 1776cc
___________________________________________________________________
2001
Le 1915cc de la 912 :
Caractéristiques moteur
|
Engine : | Type 1 1600cc | |
Builder : | EriK Z, dit Mr Z. | |
Displacement : | 1915cc | |
Crankcase : | AS21 | |
Crankshaft : | 69 mm Stateside tuning welded, counterweighted full circle, 8 doweled | |
Rods : | OEM VW rods | |
Pistons : | 94mm A model Mahle forged | |
Rings : | Cima/Mahle | |
Cam : | Engle 130, 308°duration xxxx’’ lift (valve) | |
Cam followers : | x?? | |
Pushrods : | Chromoly Gene Berg, OEM tube | |
Rocker : | OEM 1.1 :1 with GB swivel adjusting screws, Autocraft shaft | |
Valve size & make : | 42mm x 37,5mm, stainless steel | |
Heads : | C.B. Performance street éliminators dual springs, chromoly retainers ported and polished by himself | |
Compression ratio : | 9,5 : 1 | |
Ignition : | Bosh 010 distributor with blue coil | |
Carburation : | Weber Dual 44 IDF, TAYCO linkage | |
Intake manifolds : | C.B. Performance ported and polished by himself | |
Exhaust system : | Merged S&S header 1/5/8, with turbo look muffler | |
Flywheel : | 200mm 12lb, Gene berg gland nut & washer | |
Clutch : | OEM vw bus | |
Oil : | Motul oil 15w40 API: SH | |
Spark plugs : | Bosch W7DTC 3/4" reach spark plug 3 cathodes | |
Special
modifications : |
Blue printed & balanced, Full flow oilling Purflux filter 2 microns, 30mm Melling oil pump& Berg cover, ‘Gold’ Facet electric fuel pump & filter King, Scat dog house, Breather box SCAT, ... |
___________________________________________________________________
une 62
une 63
le fameuse Razmotte
un double cab 2L
une 1303 cab'
